Falmec BRERA 75 Worktop Hood – 75 cm (Black Ceramic Glass, 800 m³/h)
High-performance integrated worktop hood combining a 75 cm induction cooktop with powerful downdraft extraction (800 m³/h). Its Flex Surface “üap” pop-up system and brushless motor deliver silent, efficient capture of steam and odors directly at the cooking surface.

---

🏷️ Product Title & SKU

• BRERA 75 – Worktop Hood, 75 cm, Black Ceramic-Glass, 800 m³/h
  • SKU: 8034122901039
  • EAN: 8034122901039

---

🔎 Overview

The BRERA 75 is a 75 cm-wide worktop-integrated hood that combines cooking and extraction into a single flush-mount appliance. Crafted in black glossy ceramic-glass with a “Flex Surface” perimeter extraction system, it offers:

• Integrated Extractor: A brushless 800 m³/h downdraft motor beneath the cooktop captures fumes and steam directly at the source.

• Flex Surface (“üap”) Technology: Motorized pop-up extractor module that rises when activated (to 360 mm) and retracts flush when not in use—maintaining a clean, continuous cooking surface.

• Touch Slider Controls: Intuitive “Touch Slider” control panel with 9 power levels plus Boost for both cooking and extraction.

• Auto-Functions:

  • Automode: Extraction speed adapts automatically to cooking power.

  • Residual Heat Indicators and Auto Cut-Off Timer for each heating zone.

  • Keep Warm (44 °C), Pause, Recall, Bridge, and Chef functions for advanced cooking convenience.

• Filtration:

  • Standard Metallic Grease Filter with integrated liquid collection tray.

  • Optional Carbon.Zeo Microtech regenerable charcoal filter for duct-free recirculation.

• Versatile Installation: Operates in Extracting (ducted) or Filtering (recirculation) mode.

• Safety & Convenience: Includes Timer, Minute Minder, Safety Lock, and Automatic Pot Detection.

All technical data and dimensions below reference the official Falmec BRERA 75 datasheet (rev. 06/05/2025).

---

📐 Technical Specifications

Attribute	Specification
SKU / EAN	8034122901039 / 8034122901039
Model & Finish	BRERA 75 – 75 cm worktop hood in Black Glossy Glass-Ceramic
Design / Collection	Falmec Lab / Cooking
Technology	Flex Surface (“üap” pop-up downdraft)
Function	Extracting (ducted) / Filtering (recirculation)
Motor	Brushless Motor – 800 m³/h
Maximum Airflow (IEC 61591)	690 m³/h
Maximum Sound Level (IEC 60704-2-13)	65 dB(A) re 1 pW
Energy Class (Motor)	A+++
Control	“Touch Slider” control surface (for both hob and extractor) – 9 cooking levels + Boost; Automode; Timer; Recall; Pause; Bridge; Chef functions
Cooking Zones / Power Management	Induction cooking power from 2.8 kW to 7.4 kW (total max 7.56 kW consumption)
Filters	• Metallic grease filter (removable, dishwasher-safe; includes liquid collection tray) • Carbon.Zeo Microtech regenerable filter (optional, code KACL.1037)
Dimensions (Worktop Installation)	• Width: 750 mm • Depth: 600 mm • Height (to countertop): Flush when retracted (extractor rises to 360 mm max)
Cut-Out / Over-Top Installation	Cut-out width: 704 mm Cut-out depth: 380 mm (refer to diagram on page 2: “Over-top installation hole dimensions”)
Cut-Out / Flush Installation	Cut-out width: 704 mm Cut-out depth: 754 mm (refer to diagram on page 2: “Flush installation hole dimensions”)
Minimum Height Above Hob	Electric Hob: 150 cm Gas Hob: 150 cm
Connection & Consumption	• Voltage/Frequency: 220–240 V ~ 50–60 Hz • Maximum Consumption: 7 560 W (hood + cooktop)
Motor Power Consumption (per Speed)	• Speed 1: 11 W • Speed 5: 50 W • Speed 9: 110 W • Boost (10): 150 W (all through Ø 150 mm outlet)
Flow Rate / Pressure Curve	See “Flow Rate / Pressure” graph on page 3 for detailed performance (254 / 460 / 640 / 690 m³/h; pressures 200 / 650 / 670 / 680 Pa)
Lighting	None integrated (hood sits flush with ceiling; ceiling-mounted lighting recommended elsewhere)
Net Weight	30.3 kg
Gross Weight & Packaging	Gross Weight: 35.5 kg Volume: 0.29 m³ Packaging Dimensions: 980 × 482 × 615 mm
Optional Accessories	• KACL.1026: Silence Kit (noise-reducing silencer pipe) • KACL.1037: Carbon.Zeo Microtech regenerable filter
Country of Origin	Italy
Warranty	2 Years (when installed per Falmec guidelines)

All “maximum capacity” and “maximum sound level” values refer to the 800 m³/h brushless motor at full Speed 10.

---

🧰 What’s Included

• 1 × BRERA 75 Worktop Hood Body (75 cm, Black Glass-Ceramic)

• 1 × Metallic Grease Filter (removable, dishwasher-safe; includes liquid collection tray)

• 1 × Electronic Control Module (pre-installed)

• 1 × Remote Control (batteries included)

• 1 × Installation Bracket Kit (mounting plates, screws, spacers for over-top or flush installation)

• 1 × User & Installation Manual (cut-out templates, wiring diagrams, maintenance instructions)

Note: Motor units (e.g., KACL.1026 Silence Kit + motor, KACL.798 #41F, KACL.770 #41F, KACL.797 #4AF) and charcoal filter kit (KACL.1037) are not included and must be ordered separately.

---

💡 Features & Benefits

1. Flex Surface “üap” Pop-Up Extraction

   • Motorized Downdraft System: Extractor module rises from the worktop to 360 mm when activated, capturing fumes and steam across the entire 75 cm surface. It then retracts flush for a seamless cooktop.

2. Brushless Motor Excellence

   • High Efficiency & Low Noise: Delivers 690 m³/h net (IEC) at 65 dB(A) max—quiet for a worktop-integrated system.

   • Adaptive Speed Control: 9 extraction speeds plus Boost; Automode senses cooking intensity and adjusts fan speed automatically.

3. Integrated Induction Hob & Advanced Cooking Functions

   • 9 Power Levels (2.8 kW–7.4 kW): Delivers precision and performance for a variety of cooking techniques.

   • Convenience Features: Residual Heat Indicators, Automatic Pot Detection, Keep Warm (44 °C), Recall, Pause, Bridge, and Chef functions—all controlled via a single “Touch Slider” panel.

4. Filtration & Ducting Flexibility

   • Ducted Extraction: Connects to an external vent or compatible remote motor via a Ø 150 mm outlet for maximum 690 m³/h removal.

   • Ductless Recirculation: Install the Carbon.Zeo Microtech regenerable filter (KACL.1037) to recirculate purified air—no duct required.

5. Sleek Black Glass-Ceramic Design

   • Luxury Finish: The black glossy glass-ceramic surface conceals fingerprints and smudges when the extractor is retracted.

   • Minimalist Aesthetic: When retracted, the extractor is completely hidden, leaving only a flush cooking surface.

6. Easy Maintenance

   • Washable Grease Filter: Pop-out bracket allows quick removal; dishwasher-safe.

   • Filter Status Alerts: The “Dialogue” display indicates “CL” when grease filter needs cleaning and “CA” when the charcoal filter requires regeneration or replacement.

7. Professional-Grade Performance

   • IEC-Certified Airflow: At Speed 9, clears 640 m³/h; Boost achieves 690 m³/h (pressures up to 680 Pa). Ideal for intensive cooking scenarios.

8. Safety & Convenience

   • Safety Lock & Timer: Prevent accidental activation; built-in minute-minder and auto shut-off for each cooking zone.

   • Hob-Safe Clearances: Certified for a minimum of 150 cm above electric or gas hobs, meeting international safety standards.

---

❓ Frequently Asked Questions

1. How does the Flex Surface “üap” extraction work?
   – When extraction is turned on, the motorized module raises from the worktop to 360 mm, drawing fumes across the entire 75 cm surface. Once turned off, it retracts flush beneath the cooktop, leaving a seamless glass-ceramic surface.

2. Can BRERA 75 operate without external ducting?
   – Yes. For filtering mode, install the Carbon.Zeo Microtech regenerable charcoal filter (code KACL.1037). The hood recirculates purified air back into the kitchen.
   – In ducted mode, connect the Ø 150 mm outlet to external venting or a Falmec remote motor unit (e.g., KACL.1026 Silence Kit + motor).

3. What are the exact installation cut-out dimensions?
   – Over-Top Installation: Cut-out must be 704 mm × 380 mm (see page 2 “Over-top installation hole dimensions”).
   – Flush Installation: Cut-out must be 704 mm × 754 mm (see page 2 “Flush installation hole dimensions”).
   – Ceiling Cavity Height: Minimum 360 mm clearance from cooktop surface to underside of countertop (to allow extractor to fully recess).

4. What is the maximum height from the cooktop to the extractor?
   – The extractor rises to a maximum height of 360 mm above the worktop. Ensure at least 150 cm clearance between cooking surface and any overhead cabinets or ceiling when installed.

5. How often do I clean the grease filter?
   – The hood’s “Dialogue display” shows “CL” when it’s time to clean. Typically, clean every 2–4 weeks depending on cooking frequency. Remove the filter and wash in a dishwasher or with warm soapy water.

6. What are the power requirements and consumption?
   – Connection: 220–240 V ~ 50–60 Hz.
   – Maximum Consumption: 7 560 W (cooktop + extractor).
   – Motor Power Use: 11 W (Speed 1), 50 W (Speed 5), 110 W (Speed 9), 150 W (Boost).
   – Standby Consumption: < 0.5 W when off.

7. Is the BRERA 75 energy-efficient?
   – Yes. The combined brushless motor and induction cooktop achieve an Energy Class A+++ rating. Extraction alone is A+++, regardless of optional motor configurations.

8. What optional accessories are available?
   – KACL.1026 Silence Kit: Silencer pipe kit for ducted installations to further reduce noise.
   – KACL.1037 Carbon.Zeo Microtech: Regenerable charcoal filter for recirculation mode—bakes clean in a conventional oven.

9. What is the warranty?
   – 2 Years limited warranty covering defects in materials or workmanship when installed per Falmec guidelines.

---

🏡 Lifestyle Integration & Pairing Ideas

1. Open-Plan Entertaining:
   Install BRERA 75 on an island to maintain an unobstructed view between living and cooking areas. The “üap” pop-up extractor disappears when not in use, preserving a clean, minimalist aesthetic.

2. Professional-Level Cooking:
   For steam or wok cooking, select Speed 9 or Boost (Speed 10) to achieve 640–690 m³/h extraction instantly—ideal for intensive culinary sessions. Pair with KACL.1026 Silence Kit to further dampen noise for a restaurant-style experience.

3. Condo & Apartment Installations:
   When external venting is impractical, use the Carbon.Zeo Microtech filter (KACL.1037) for fully duct-free operation. Enjoy fresh, odor-free air without visible ductwork—perfect for high-rise living.

4. Sleek Minimalist Designs:
   The black glossy ceramic-glass top blends seamlessly with dark countertops or contrasting marble islands. When retracted, the extractor is invisible—matching the ethos of contemporary Scandinavian or modern industrial interiors.

5. Safety-First Family Cooking:
   Automatic pot detection, Safety Lock, and the induction hob’s cool-to-touch surface make BRERA 75 an excellent choice for families or households with young children.

6. Green Building & Efficiency:
   With Energy Class A+++, a brushless motor, and regenerable filters, BRERA 75 supports eco-friendly renovation projects or green building certifications.

---

👉 Elevate your kitchen—order the Falmec BRERA 75 Worktop Hood (Black 8034122901039) today and choose your ideal ducting or recirculation accessories!
