💡 Lainox Naboo Reloaded Combi Oven – Model NAEM171R
• SKU / Product Code: NAEM171R • “Automatic Interactive Cooking | 10-inch Touch & Cloud Connectivity”

Quick-view: 7 × GN 1/1 + 10 × GN 1/1 stacked electric combi oven with boiler/direct steam, 26.5 kW, 10-inch capacitive touch, Wi-Fi Nabook™ cloud, automatic LM cleaning, multi-level & JIT workflow. Fits 930 × 825 × 1925 mm footprint; feeds 130–270 meals per run.

─────────────────────────────
🔥 Advanced Cooking & Heating Features

• Convection 30 - 300 °C, Steam 30 - 130 °C, Combi 30 - 300 °C with instant start

• ICS® automatic recipe library + programmable 15-step sequences

• MultiLevel PLUS & Just-In-Time double capacity scheduling

• AutoClima® humidity control & Fast-Dry® chamber dehumidification

• EcoSpeed®, EcoVapor® & TurboVapor® energy-/water-saving steam management

─────────────────────────────
🔧 Smart Safety & Control Features

• IPX5 water-jet protected front & electronics

• Quad safety suite: chamber thermostat, pressure/depression valve, fan motor thermal guard, magnetic door switch

• Self-diagnosis with audible alerts & service test program

• HACCP & Energy Monitor with remote service via Wi-Fi

─────────────────────────────
💎 Premium Design & Build Quality

• 18/10 AISI 304 one-piece chamber, 1 mm steel, rounded corners

• Double-tempered heat-reflecting glass door; internal pane folds for cleaning

• Armoured Incoloy 800 heating elements & fully-insulated boiler

─────────────────────────────
🏡 Lifestyle Integration & Pairing Ideas

• Central production kitchens: stack NAEM171R beside a matching Naboo GN oven to synchronise menus via Nabook Cloud.

• Hotel banqueting: MultiLevel PLUS doubles output on each shelf, ideal for plated service.

• Smoke house: add optional SmokeGrill 3-in-1 module for barbecue, smoking and flavouring in one cavity.

─────────────────────────────
📏 Installation & Dimensions

• External (W × D × H): 930 × 825 × 1925 mm

• Electrical: 3N~ 400 V, 50/60 Hz, 26.5 kW, 46 A

• Water: soft & cold dual inlet, automatic boiler drain < 60 °C

• Vent: Ø 150 mm collector or NKC171 air-cooled hood option

Logistics: Packed size 1000 × 1000 × 2000 mm, Net / Gross 268 / 310 kg

─────────────────────────────
📦 Package Contents & Accessories
• Included: 10″ touch module, 2 × Ø 3 mm multipoint core probes, LM auto-clean tank (990 g), CALOUT descaler tank (990 g)
• Optional: Needle probe Ø 1 mm, SmokeGrill kit, extraction hood, removable racks, detergent CPD20, fat filter NFX02, marine kit

─────────────────────────────
✨ Key Features & Benefits

• 10″ HD Touch & Cloud: intuitive swipe UI, recipe sync, energy + HACCP monitoring.

• Boiler/Direct Steam Hybrid: instant saturated steam for delicate fish or tough pasta.

• Automatic LM Wash: closed-loop dosing cuts labour and chemical contact.

• Cal-Out Anti-Scale: prevents limescale, extends boiler life, alerts when service needed.

• Energy & Water Optimisers: EcoSpeed/EcoVapor save utilities up to 20 %.

─────────────────────────────
📝 Notes
Ensure 300 mm rear service clearance for water, drain and electrical connections. Run CALOUT cycle monthly in hard-water areas. Marine kit required for shipboard installation.

─────────────────────────────

⚙️ Comprehensive Technical Specifications

Parameter	Value
GN capacity	7 × 1/1 GN + 10 × 1/1 GN stacked
Shelf spacing	70 mm
Meals per batch	130 – 270 servings
Heating outputs	Chamber 25 kW; Steam 15 kW; Fan 1.5 kW
Protection rating	IPX5 front panel
Safety devices	Over-temperature, pressure relief, water-loss, door magnet, fan thermal cut-out
Cleaning system	LM automatic liquid-dose + hand shower
Connectivity	Wi-Fi Nabook Cloud, optional Ethernet
Construction	1 mm AISI 304 chamber, double glass door, Incoloy 800 elements

─────────────────────────────
❓ Frequently Asked Questions (FAQ)

1. Is fresh-water softening mandatory?
   A soft-water inlet is required; efficiency monitor warns if external softener fails.

2. Can I cook different foods simultaneously?
   Yes—MultiLevel PLUS assigns independent timers and climate to each shelf.

3. What maintenance does the boiler need?
   Automatic daily drain/rinse; CALOUT alerts when semi-automatic descaling is due.

4. Does the oven log HACCP data?
   Full temperature & probe logs are stored and exportable via Nabook cloud.

5. How much power should I provision?
   3-phase 400 V, 46 A breaker for 26.5 kW load.

6. Is there a gas version?
   NAEM171R is electric only; gas heating figures are listed as n/a.

7. Can I retrofit left-hand door?
   Yes—order kit NPS171 for opposite hinge.

8. What cleaning chemicals are required?
   Use Combiclean liquid (DL010) and Calfree descaler (CF010), one 990 g tank each supplied.

9. Is remote diagnostics possible?
   Nabook remote service lets technicians access logs and run tests online.

─────────────────────────────
👉 Bring Michelin-level precision to large-scale kitchens with the Lainox Naboo Reloaded NAEM171R—faster workflow, cloud intelligence and savings baked in.
